Compact Automatic Edge Banding Machine
The Bestin’s compact edgebander BEDF2 is designed for precision and speed. It features a comprehensive range of edge processing units for high-quality edge band results.
This machine handles edge banding thicknesses from 0.4 to 3 mm with ease. It can ensure professional finishes through automatic feeding and precision trimming, scraping, and polishing units.
Built with heavy-duty construction to reduce vibration, it ensures consistent accuracy, making it ideal for workshops of all sizes.
Benefits
- Precision and Stability
The heavy-duty chain-driven track with rubber-padded guides ensures smooth, stable, and precise workpiece movement, preventing surface damage during operations.
- User-Friendly Operation
The optional 10” touchscreen controller simplifies machine control, making it easy for operators to adjust settings, troubleshoot issues, and monitor performance in real-time.
- High-Speed Edge Processing
Equipped with powerful trimming and polishing motors operating at high RPM, it ensures perfect edge finishing at impressive speeds.
- Optimized Productivity
The automatic edge material feed and multi-station setup allow for continuous operation with minimal manual intervention, enhancing production output.
Features
- Full Edge Banding Process Unit
Pre-milling, glue pot, pneumatic guillotine, pressure station, end trimming, top & bottom fine edge trimming, scraping, and edge polishing for comprehensive edge banding operations.
- Optional 10” TFT LCD Touch Screen Controller
Includes PLC parameter editing, service and alarm history, and alarm notification features for easy machine management.
- Automatic Material Feeding
Synchronous feeding of edging materials (tape) with the panel feed ensures smooth, consistent operation.
- Heavy-Duty Construction
Built to withstand heavy use with a robust structure that eliminates vibration and ensures stability and precision.
- Efficient Pre-Milling Unit
Dual diamond cutter heads prepare panel edges for optimal bonding, ensuring a flawless finish.
- Sound & Safety Covers
Protect all work units while minimizing noise and ensuring dust extraction, keeping the workspace clean.
Technical Data
Working Area(X*Y*Z) |
2100*4200*200mm |
Cutting Accuracy |
±0.03/1000mm |
Table Surface |
Vacuum Adsorption Table |
Material Positioning
Method |
Repeat Positioning By
Positioning The Cylinder. |
Frame |
Heavy-Duty Industrial Class
Square Tube Strong Structure |
X, Y Structure |
Rack And Pinion Drive, Germany
ASK #25 Rail Linear Bearings |
Max. Rapid Travel Rate |
50000mm/Min |
Max. Working Speed |
30000mm/Min |
Z Structure |
Taiwan Ball Screw |
Spindle Power |
Italy HSD 9KW Air Cooling
Spindle |
Operating System |
Taiwan SYNTEC 60W-E Control
System |
Drive Motors |
Japan Yaskawa Drive And Yaskawa
850W Servo Motors |
Vfd |
11kw Delta Vfd |
Spindle Speed |
0-24000rpm |
Working Voltage |
AC380v, 50hz,3ph (Option: 220v) |
Command Language |
G Code |
Control Box |
Place The Computer’s Big Control
Box |
Collet |
Er25 |
Software Compatibility |
Art Cam/Power Milltyep 3 |
Lubrication System |
Automatic Lubrication System |
