Single Surface Planer
Single Surface Planer
- Precision Connecting-Rod System
- Ribbed Cast-Iron Tables (1800 × 598 mm)
- Spiral Cutterhead
- Noise-Dampening Design
- Quick-Release Fence with Aux. Guide
Single Surface Planer
The BESTIN VK-B523M Single Surface Planer combines precision mechanics with a heavy-duty build to deliver lifetime accuracy, silent operation, and exceptional surface quality.
Its connecting-rod guide system ensures perfectly fluid table movement without deformation, while ribbed cast-iron tables eliminate vibration.
The spiral cutterhead generates tiny, uniform chips for an outstanding finish, superior dust extraction, and up to 10 dB noise reduction.
Ergonomic controls, a quick-release fence, and a powerful 2.2 kW soft-start motor make this planer a workhorse for any professional workshop.
Benefits
- Lifetime Precision & Stability
The patented connecting-rod guide system guarantees fluid, backlash-free table movement and prevents any worktable deformation, ensuring consistent flatness and jointing accuracy over the machine’s lifetime.
- Total Vibration Elimination
Large, ribbed cast-iron tables dampen cutting forces, eliminating vibration and ensuring a rock-solid foundation for precision planing.
- Exceptional Surface Finish
The spiral cutterhead—with three spiraling carbide knives—slices diagonally across fibers, producing ultra-smooth surfaces and minimizing tear-out on both soft and hard woods.
- Quieter, Cleaner Operation
Spiral knife geometry reduces cutting noise by up to 10 dB and generates small, uniform chips that improve dust-collector efficiency and air quality in the workshop.
- Ergonomic, Fast Setup
A quick-release fence with integrated auxiliary guide allows rapid, tool-free adjustments for narrow strips, while electronic soft-start and braking on the 2.2 kW motor reduce wear and enhance safety.
Features
- Precision Connecting-Rod System
Guarantees fluid, deformation-free table movement and lifetime accuracy.
- Ribbed Cast-Iron Tables (1800 × 598 mm)
Heavy-duty support that absorbs vibration for rock-solid planing.
- Spiral Cutterhead
Diagonal slicing action delivers a superior, tear-free finish and long insert life.
- Noise-Dampening Design
Up to 10 dB(A) quieter cutting for a comfortable workshop environment.
- Quick-Release Fence with Aux. Guide
Fast, ergonomic fence adjustments for thin or narrow stock.
- Electronic Soft-Start & Brake
Smooth startup and rapid motor stop enhance safety and prolong motor life.
Technical Data
| VK-B523M | VK-B524M | |
| Maximum Planing Width | 300 mm | 400 mm |
| Max. cutting depth | 4 mm | 5 mm |
| Spindle Speed | 5600 r/min | 5000 r/min |
| Number Of Blades | 3 | 4 |
| Cutting Circle Diameter | Φ87 mm | Φ102 mm |
| Total Length Of Table | 1800 mm | 2000 mm |
| Motor Power | 2.2 kW | 3 kW |
| Motor Speed | 2840 r/min | 2880 r/min |
| Overall Dimension | 1800×598×100 mm | 2000×790×1100 mm |
| Net Weight Of Whole Machine | 290 kg | 391 kg |
